AS-552035 3.7v 350mAh LiPo Battery
Lipo Battery Supply
Product Specifications
- Model No.: AS-552035
- Voltage: 3.7v
- Capacity: 350mah
- Cycle life:over 500times
- Material:Li-polymer battery
- Unit Size :5.7*21*37.5mm
- Weight:7.0g
- Certification: UL/IEC62133/CE/ROHS/UN38.3 KC
Product Introduction
| Item | Rating | Note | ||
| 3.1 Capacity | Typical | 350mAh | Discharge:0.2CmA
cut off Voltage:3V for cell |
|
| Minimum | 330mAh | |||
| 3.2 Nominal Voltage | Average 3.7V | Discharge:0.2CmA
cut off Voltage:3V for cell |
||
| 3.3 AC Impedance Resistance | ≤320mΩ | |||
| 3.4 Discharge Cut-off Voltage | 3.00V | |||
| 3.5 Charge Current | 150mA | |||
| 3.6 Charge Voltage | 4.2V | |||
| 3.7 Max. Charge Voltage | 4.23V | |||
| 3.8 Charge Time | Approx 6.0h | Charge: 0.2CmA | ||
| 3.9 Max. Charge Current | 350mA | 1.0CmA | ||
| 3.10 Max. Discharge Current | 350mA | 1.0CmA | ||
| 3.11 Weight | Approx7.0g | |||
| 3.12 Operating Temperature | Charge | 0~+40℃ | ||
| Discharge | -20~+60℃ | |||
| 3.13 Storage Temperature | less than 1 month | -20~+45℃ | Recommended storage
temperature: 20℃,at the shipment state |
|
| less than 3 months | -20~+35℃ | |||
Applications
*smart wearable device
*GPS Tracker
*Eye massager
*The above data is for reference only. CONTACT US for detailed information and customized solutions.
