12v 5Ah Lifepo4 Battery Pack
Cycle life:over 2000times.
Product Specifications
- Model No.: AS-7365132
- Battery Type: Lifepo4 Battery
- Voltage: 12V
- Capacity: 5Ah
- Unit Size : 73*65*132mm
- Cycle life:over 2000tims Accept OEM order and samples order.
- Application: Solar Street Light /Storage Energy
Product Introduction
| Item | Rating | Note | ||
|
3.1 Capacity |
Typical | 5Ah | Discharge:0.2CmA | |
| Minimum |
4.8Ah |
|||
|
3.2 Nominal Voltage |
Average 12.8V |
|||
|
3.3 Discharge Cut-off Voltage |
10V |
|||
|
3.4 Charge Current |
1A |
Standard Charge |
||
|
3.5 Charge Voltage |
14.6V |
|||
|
3.6 Charge Time |
Approx 8h |
|||
|
3.7 Max. Charge Current |
5A |
|||
|
3.8 Continuous discharge current |
5A |
|||
|
3.9 Max. discharge current |
15A |
|||
|
3.11 Operating Temperature |
Charge | 0~45℃ | ||
| Discharge |
-20~60℃ |
|||
|
3.12 Storage Temperature |
less than 1 month | -20~45℃ |
Recommended storage temperature: 20℃,at the shipment state |
|
Product Advantage
1) Environmental friendly
2) High density of energy
3) Light weight
4) Low self-discharge
5) Low internal resistance
6) Long cycle life, chargeable up to 2000 times
7) No memory effect
8) Doesn’t contain Mercury, No fire, No explosion, No leakage
Applications
*Solar Street Light
*Storage Energy
*The above data is for reference only. CONTACT US for detailed information and customized solutions.
